Still FM-X Reach Truck Lithium Battery 51.2v 404ah

The Still FM-X Reach Truck is designed for high-performance material handling. Initially, it runs on a 48V/465Ah lead-acid battery (model: 48V3PZS465), but it can now be upgraded to a 51.2V/404Ah lithium-ion battery. This upgrade improves efficiency, reduces maintenance, and lowers weight, resulting in better performance and extended operating time.

Product Description

The original 48V/465Ah lead-acid battery weighs 761kg and fits in a compartment measuring 1210mm x 268mm x 720mm. After upgrading to the 51.2V/404Ah lithium-ion battery, the new battery will weigh only 230kg. However, the forklift will need an additional 531kg counterweight to ensure proper stability.

• Same Dimensions: The 51.2V/404Ah lithium-ion battery fits the existing compartment of 1210mm x 268mm x 720mm. No modifications are needed for installation.

• Lighter Battery: The lithium-ion battery weighs 230kg, significantly lighter than the original 761kg lead-acid battery. A 531kg counterweight is necessary to balance the forklift after the upgrade.

• Improved Performance: The lithium-ion battery, though having a slightly lower capacity of 404Ah, offers faster charging and longer operational hours, reducing downtime.

Product Specifications

• Original Lead-Acid Battery:

  • Type: Lead-Acid

  • Voltage: 48V

  • Capacity: 465Ah

  • Dimensions: 1210mm x 268mm x 720mm

  • Weight: 761kg

• Upgraded Lithium-ion Battery:

  • Type: Lithium Iron Phosphate (LiFePO4)

  • Voltage: 51.2V

  • Capacity: 404Ah

  • Dimensions: 1210mm x 268mm x 720mm (same as original)

  • Weight: 230kg

  • Counterweight: 531kg required

  • Charging Plug: Compatible with standard industrial chargers

Before and After Upgrade Comparison

Installation and Application

• Seamless Installation: The 51.2V/404Ah lithium-ion battery fits directly into the existing compartment of the Still FM-X Reach Truck. No modification is needed.

• Reduced Weight and Counterbalance: The new 230kg lithium-ion battery is much lighter than the original. To maintain proper balance, a 531kg counterweight is required after the upgrade.

• Low Maintenance: Unlike lead-acid batteries, lithium-ion batteries need minimal maintenance. No need for regular water checks or cleaning.

• Eco-Friendly: The LiFePO4 lithium-ion battery is safer and more environmentally friendly compared to lead-acid batteries. It contains no hazardous materials and is fully recyclable.
